65 - 70 Mustang Heidts PRO-G Front Suspension Kit, Gen 2 Design
65 - 70 Mustang Heidts PRO G Coil-Over Front Suspension System, 2nd Gen Design
This new pro-touring front suspension kit will give your classic 65 - 70 Ford Mustang unbelievable steering, handling and cornering capabilities. This front suspension kit has been completely redesigned to install everything from Small Block engines and big block engines to the new Ford Modular engine family, including the new 5.0 Coyote Engine. The classic Mustangs suffer from sloppy and vague steering and handling characteristics that make your Mustang not very much fun to drive. However, this Heidts Pro-G front suspension system will make your Mustang handle like a modern sports car eliminating bump steer and allowing the car to handle and steer with complete precision. IMPORTANT: This front suspension has a 58 Inch Overall Track width (Measured from Rotor Hub Face to Hub Face) See tabs below for more information about this exciting new suspension.
Sold as a KIT
Product Features
Frame Rail Reinforcement Kit to Box Stock Frail Rails
Main Front Cross Member Kit with Lower Control Arm Mounts
Heavy Duty Engine Stands Built Into Cross Member
Upper Coil-Over Shock Mounts with 2 Position Mount Holes for Height Adjustment
Tubular Upper Control Arm Package with Poly Bushings
Tubular Lower Control Arm Package with Poly Bushings
Power Rack and Pinion Kit with Mounts and Tie Rod Kit
Forged Steel 2 inch Drop Pro-G Spindle and Steering Arm Kit
Coil-Over Shocks and Springs
11 Inch Wilwood Disc Brake Kit with 4 Piston Forged Aluminum Calipers
All Hardware Needed to Install Suspension/Steering Components
Complete Install Instruction Booklet
Benefits of This PRO-G Front Suspension Kit:
Strength
Strengthens Classic Mustang front Frame and Engine bay The kits rigid welded and boxed front
cross member and frame plate assemblies helps reduce unwanted chassis flex.
Steering
Vastly improved steering geometry over the stock front suspension to completely eliminate and Bump Steer -Bump steer is when the steering pulls to the left or right when going over a bump.
Precise Steering with modern quick ratio rack and Pinion steering kit
Tubular Control Arms
The Dual A-Arm Control arms in this kit (Also known as a Long Arm/Short Arm Configuration) provide precise movement of the spindle/rotor assembly to eliminate unwanted negative changes in suspension geometry. The strong arms will not flex like weaker stamped units and will not allow for unwanted toe changes during hard acceleration and braking. The arms also allow for an improved negative chamber curve for better tire contact to the pavement under loads. Lastly, the arms are designed for a higher amount of positive caster to improve high speed turn-in and stability.
Disc Brakes
The Pro-G Front Suspension utilizes modern disc brake kits manufactured by the leader in braking technology - Wilwood Engineering. The Wilwood disc brake kit provides excellent stopping power and consistent trouble-free performance. With features like Forged Aluminum Caliper Bodies, Multi-Piston calipers and Machined aluminum hub assemblies (on Upgraded Kits) there is a Wilwood brake kit for all types of driving from mild street use to true high performance.
Important Install Notes
This kit requires the original shock towers to be permanently removed from the Engine Bay.
See recommended items below for the Heidts Inner Panels that will cover where the shock towers are removed. Part # PX-325 for 65-66 and Part # PX-326 for 67-70 Mustangs.
Kit requires the use of a Fox Body Style rear sump oil Pan (to clear the front mounted rack and pinion Kit) Kit Requires welding the main cross member and lower arm supports to the front Frame Rails.
Total Front Track width is 58" - Measured from Rotor Hub Face to Rotor Hub Face
