65-70 Mustang TCI 3 Link Rear Torque Arm Kit, Mini Tub Version
65 - 70 Mustang TCI Rear Torque Arm (3 Link) Kit, WIDE TIRE VERSION, with Sub-Frame Connectors, Center Chassis Brace and Drive Shaft Safety Loop Kit
Introducing A Rear Toque Arm 3 Link Suspension Package with Mini Tub Kit for extra Wide Tires for your 65 66 67 68 69 or 70 Mustang Fastback Or Coupe. This Package allows for large 315 - 335MM Rear Tires. This new Wide Tire Mini Tub kit moves the lower control arms to the inside of the rear frame rail and includes a new straight frame section with wider inner wheel house to give you an extra 2 inches of room per side over the stock inner wheel house and frame rail configuration. The TCI Torque arm kit will do an excellent job of controlling the rear axle housing and keeping it firmly planted to the ground eliminating wheel hop and controlling lateral movement of the axle housing for a huge improvement over the stock rear leaf spring configuration. The rear coil-over and stacked tube coil-over mounting points will allow you to lower the rear end 2 to 3 inches lower than stock. The torque arm does an excellent job of keeping the rear end stable under high horsepower and demanding performance driving conditions. Put some serious control and performance in the back of your classic Mustang with this new performance rear suspension package!
PLEASE NOTE: Axle housing/3rd member and brakes do not come with the suspension kit. We can however, put together a complete rear end and brake package for your needs, please call to inquire.
Sold as KIT
Special Notes
**Will Fit 65-70 Coupes or Fastbacks Only. (Convertible Version not available)
- Lower the Stance of your Classic Mustang
- Dramatically Improve Handling and Braking
- Bult to Control your torque and get the horsepower to the ground
- Elimate Wheel Hop When Accelerating
- Keep the Rear Housing Centered Under the Car When Driving Aggressively Through Turns and Corners. Therefore, providing superior handling and stability over the out-dated leaf spring design.
- Allows enough room to install 315 - 355 MM tires in the rear (with Mini Tub Kit Install)
- Inlcuded Extra Upper Reinforcement Bar for extra lateral strength
This suspension package is NOT A bolt in product. Welding of the new rear fram section, inner wheel houses, and upper cross member to inside frame saddles is required. Do Not Attempt to Install this Suspension System unless you have prior experience and knowledge with suspension systems and welding.
This Kit Includes:
- Full Length Subframe Connector Kit
- Bolt-In Center Chassis Stiffener Support
- Adjustable Torque Arm Bar
- Rear Panhard Bar
- 1-1/4 Inch Diameter High Horsepower Lower Control Arms
- Frame Brackets
- RideTech Single Adjustable Billet Coil-Over Shocks (million mile warranty included)
- Powder Coated Coil Over Springs
- Upper Shock Cross-Member
- Upper Lateral Support Bar with Adjustable Ends
- Rigid Torque Arm Assembly
- Adjustable 3rd Member Supports
- Driveshaft Safety Loop
- Rear Frame Reinforcement Plates
- Mini Tub Kit with Inner Wheel Houses and New Frame Sections with Gussets
Let Stang-Aholics help turn your classic Mustang into a corner hugging, stop-on-a-dime muscle car!
IMPORTANT NOTE: 9 Inch Housing/3rd Member And Rear Brakes Are Not Included and Are Pictured for Display Purposes Only. The axle brackets in this kit are designed to fit a 9" Housing with 3 Inch tubes. Tappered 9 Inch tubes will require additional welding/modification. Complete New-Style Big Ford 9 Inch Housings/Axles/ 3rd Members and Brake Kits Are Available Seperatlely.
Technical Notes
**PLEASE NOTE: Because the rear wheel housings in this kit, are approximately 2 Inches wider than stock, the stock rear interior side panels will need to be trimmed/modified to accommodate the larger inner wheel housings. The rear seat will also need to be removed or narrowed to accommodate the wider rear wheel housings.
Details
- 530-5102-00-WT
- 530-5102-00-WT
- Total Cost Involved
- New
Shipping Information
- Item Requires Shipping
- FREE SHIPPING on orders *$199 or more
- This item ships in its own box.
- This item will require a special quote for shipping charges.
- FREE SHIPPING via Truck Freight to lower 48 states. Best to ship to a Commercial Business Address if Possible.
